Non-touchscreen
10.4 Inch IPS Lcd TFT Bar Shape LCD Display Panel
10.4 Metal stretched lcd bar Resolution：1280*205 Display area：261.2*42mm
10.4 Inch IPS Lcd TFT Bar Shape LCD Display Panel
Modern businesses rely on accurate, real-time information to improve customer experience and operational efficiency. Whether installed in transportation hubs, hospitals, retail stores, factories, or office buildings, a reliable lcd information display helps organizations communicate clearly while reducing the need for printed signage.
The 10.4 Inch IPS TFT LCD Information Display is designed for commercial applications that require stable performance, wide viewing angles, and long-term operation. Featuring an industrial-grade IPS panel, high image quality, and flexible integration options, this display is suitable for OEM projects, intelligent information systems, and customized digital signage solutions.
As a factory specializing in commercial LCD displays, we provide complete Factory Direct, OEM, and ODM services for customers across the United States, Europe, the Middle East, and other global markets.
IPS Technology Delivers Superior Viewing Performance
The 10.4-inch display utilizes an IPS TFT panel that provides excellent image quality from multiple viewing angles.
Benefits include:
Wide Viewing Angles
Customers can clearly read information from different positions without color distortion.
Stable Color Performance
Images, text, and graphics remain vivid even after extended operation.
Better User Experience
Whether displaying advertisements, schedules, instructions, or notifications, IPS technology ensures every message remains clear.
Ideal for Multi-Industry Information Display Applications
One of the biggest advantages of this lcd information display is its versatility.
Transportation Information Systems
Bus stations, subway platforms, railway terminals, and airports require reliable digital displays for schedules and passenger guidance.
The 10.4-inch display is suitable for:
- Platform information
- Departure schedules
- Boarding instructions
- Digital wayfinding
Its compact size allows installation where conventional displays cannot fit.
10.4 Inch Stretched LCD | ||
Display Specifications | ||
Screen Size | 10.4 inch | |
Resolution | 1280*205 | |
Brightness | 400 cd/㎡ | |
BLU | LCD | |
Contrast Ratio | 700:1 | |
Viewing Angle(H/v) | 80°/80°/70°/70° (Typ.)(CR≥10) | |
Backlight Life | 60,000(hrs) | |
Panel Parameters | ||
OS | Android | |
CPU | T972,Quad-core ARM,Cortex-A55,1.9GHz | |
RAM | 2GB | |
ROM | 16GB | |
Network | WH-Fi/LAN/ BT4.2 | |
l/O Interface | USB2.0x 1/Micro USB x 1/TF Cardx 1/DC IN x 1/RESET x 1 | |
Power Specifications | ||
Power Supply | AC 100V~240V, 50/60Hz | |
Power Consumption | ≤ 15w | |
Environment Specifications | ||
Operation Temperature | below10℃ ~ +50℃ | |
Operation Humidity | ≤ 90%RH | |
Smart Building Management
Commercial buildings increasingly use digital information displays to improve visitor experience.
Typical applications include:
- Elevator information panels
- Floor directories
- Reception displays
- Meeting room schedules
- Visitor notifications
The display supports both standalone and network-based content management.
Manufacturing & Industrial Environments
Factories require real-time production information to improve efficiency.
The display can present:
- Equipment operating status
- Production targets
- Safety reminders
- Maintenance notifications
- Workflow instructions
Its industrial design makes it suitable for long-term deployment.
Product Dimension as follows:
Why International Customers Choose Our Factory
Customers choose us because we provide more than display hardware.
Our advantages include:
- Factory Direct manufacturing
- OEM & ODM capability
- Experienced engineering team
- Strict quality management
- International export experience
- Fast production lead times
- Technical support before and after delivery
- Flexible customization for commercial projects
Whether your order is a prototype or a large-volume deployment, we deliver consistent quality and reliable service.
Frequently Asked Questions
Q1. What is an LCD information display used for?
It is used to display real-time information, advertisements, schedules, directions, and notifications in commercial and public environments.
Q2. Can the display be customized?
Yes. We provide OEM and ODM services, including hardware, software, housing, and interface customization.
Q3. Do you offer Factory Direct pricing?
Yes. All products are manufactured in our own factory, allowing us to offer competitive pricing and stable quality.
Q4. Do you support international distributors?
Yes. We work with distributors, system integrators, wholesalers, and OEM brands across North America, Europe, the Middle East, and other regions.
Q5. How can I request a quotation?
Simply send us your required specifications, quantity, application, and customization needs. Our engineering team will recommend the most suitable solution and provide a detailed quotation.
